Leeze
AC 35 Road
AC 35 Road
Standard / Shimano
Leeze Bike Store
Hohenholter Straße 25
Leeze GmbH
48329 Havixbeck
Germany
Select options
The AC 35 Road is an absolute top performer. Its rim features a special alloy, allowing for very high stiffness despite its relatively low weight. With a rim width of 20mm, it's possible to follow the trend and ride wider tires. Visually, this wheelset is also a real eye-catcher with its black anodized braking surface. The AC 35 Road is your perfect wheelset if you are looking for a robust yet very agile wheelset for everyday rides in flat to mountainous terrain.
Note: Over time, the black coating on the braking surface may wear off. Riding in the rain significantly accelerates this effect. To prevent wear on the braking surface, brake pads should be checked for foreign objects, especially after riding in the rain.
| Weight1 | 1460 g (3% tolerance) | |
| Wheel material | Aluminum | |
| Wheel type | 20-622 with hook | |
| Braking system | rim brake | |
| Rim height | 35 mm | |
| Wheel width | 24 mm | |
| jaw width | 20 mm | |
| Logos | black, painted | |
| Tire type | Folding/clinchers, tubeless-ready | |
| Tire widths | 25-40 mm | |
| Hub | Leeze Road EVO Front & Road Advanced Rear | |
| freewheel | Shimano/SRAM 10-/11-speed, SRAM XDR 12-speed, Campagnolo | |
| Axle standard | Quick Release (5x100 mm, 5x130 mm) | |
| Number of spokes | 18/24 | |
| Spokes VR | Sapim CX-Ray (bladed spokes), radial | |
| Spokes HR | Sapim CX-Ray (bladed spokes), radial / Sapim CX-Sprint (bladed spokes), 2-cross | |
| Weight limit | 110 kg system weight |
- Wheel set
- Valve stickers to prevent valve rattling (2 pcs.)
- 2x tubeless rim tape (already installed)
- Leeze Quick Release Set Standard
Available to match your wheelset: tubeless valves, tire kits, brake rotors, and cassettes.
Manufacturer's part number: LRS-10491-01
Here you'll find detailed instructions on how to use and maintain your wheelset:
Please observe the following safety instructions to ensure your safety and the longevity of your wheels. The accompanying or online user manual is an integral part of the product and must be read in its entirety before use.
Do not exceed the specified maximum total weight (rider + bicycle + luggage). Exceeding this limit can lead to equipment failure and cause a fall resulting in serious injury.
Do not exceed the specified maximum tire pressure. Always take into account the combination of tire, rim, and setup (reduced maximum pressures, especially for tubeless and hookless setups)! If different values apply to the wheel and tire, the lower value is always the valid maximum. Excessive pressure can cause a tire blowout and thus lead directly to crashes resulting in serious injuries.
Use only tire types and sizes approved in the datasheet (especially for tubeless and hookless setups). Incorrect combinations can lead to tire defects or tire blow-off, directly causing crashes with severe injuries.
The installation, removal, and maintenance of safety-relevant components (e.g., spokes, hub bearings, tubeless setup, quick releases, cassette, brakes) must only be performed by qualified specialist personnel. Improper execution can lead to material failure and serious accidents.
Always tighten the cassette with a torque wrench and observe the torque values specified by the respective manufacturer. Grease the freehub body before installing the cassette to prevent the sprockets from digging in. Use only brake pads approved for the respective rim material and align them so that they fully contact the braking surface without touching the tire or rim edge. Always keep braking surfaces clean and replace worn pads promptly.
When mounting or dismounting tires, use only plastic tire levers as a last resort, never metal levers or other hard objects, to avoid damage to the rim and tire.
For quick releases, ensure correct tension and secure closure with noticeable resistance. Align the lever so that it cannot be opened unintentionally, and check for a secure fit before every ride.
Only use the wheelset for its intended purposes (e.g., road bike or gravel), see link: Leeze Application Areas. Use the wheelset only with disc brakes. Do not expose the wheels to high temperatures (e.g., in a car in the sun or leaning against a radiator). Not suitable for downhill, BMX, jumps, cargo transport, or other extreme forms of use.
Regularly check your wheels for cracks, delamination, and damage to spoke holes, brake track, or rim bed. For optimal spoke tension and trueness, we recommend wheel checks every 5,000–10,000 km, every 12–24 months, or after 6 months of inactivity. If damage is suspected, stop riding immediately and contact Leeze service. In case of doubt, discontinue use immediately and consult the manufacturer or a specialist dealer.
Clean rims, spokes, and hubs regularly with mild soap and water; avoid high-pressure cleaners and direct water jets on bearings. Store wheels dry and dry them after wet rides. For extended periods of inactivity (>6 months), we recommend a bearing and wheel check. Clean and grease the freehub system regularly. For tubeless systems, replace sealant and rim tape at least twice a year to prevent damage to spoke nipples. Negligence in maintenance can lead to premature wear, malfunctions, or sudden failure during a ride, thus posing a safety risk.
Stop riding immediately and have the wheels professionally inspected, even for minor or invisible damage. Invisible cracks in the carbon can lead to sudden breakage and a crash.
